HYBRID INVERTER WE-IVH5000
HIGH YIELD
· Max.efficiency 97.6%
· DualMPPTs
SAFETY AND RELIABILITY
· TypelISPD onAC&DCside
· Support export limitation
· AFCIfunction optional
· Natural cooling design
INTELLIGENT MAINTENANCE
· Compatible with lead-lead batteries arlithium battery energy storage systems
· Remote configuration and upgrade
Series:
Environmental protection
Keyword: Solar pump | Inverter & Energy Storage System
- 产品描述
-
- Commodity name: HYBRID INVERTER WE-IVH5000
- Commodity ID: MZ-IVH5000
HIGH YIELD · Max.efficiency 97.6% · DualMPPTs SAFETY AND RELIABILITY · TypelISPD onAC&DCside · Support export limitation · AFCIfunction optional · Natural cooling design INTELLIGENT MAINTENANCE · Compatible with lead-lead batteries arlithium battery energy storage systems · Remote configuration and upgrade
Model MZ-IVH3700 MZ-IVH4600/MZ-IVH5000 Battery input Data Battery voltage Range(Vdc)
Max.ContinuousDischargingcurrent(A)
Max Charging PowefMax.Discharging Power(w)85Vdc-450vdc 14.8A 20A 3700w 5000W pVString Input Data Max.InputPower(W) 4500w 6000w MPPTOperating voltage Range(vdc) 125vdc-55ovdc Max.lnputcurrent per MPPT(A) 13.5A 13.5A Max.Short Circuit Current per MPPT(A)
Number of MPPTS15.2A 15.2A 2 Number of Stringsper MPPT 1 AcoutputData(on-grid) N ominal ApparentPower output to utility Grid(vA) 370OVA 5000VA NominalOutput Voltage(Vac) 230Nac NominalAC GridFrequency (Hz) 50Hz Max.AcCurrent Output to utility Grid(A) 17.8A 24A Ac outputData(EPS) EPSNominal Apparent Power(MA) 3700VA 5000VA Max.ou tput Current(A) 17.8 24A Nominaloutput Voltage(Wac) 230Vac(士29%) Nominaloutput Frequency (Hz)
Efficiency
Max.Efficiency50Hz/5OHz(士0.296) 97.6% EuropeanEfficiency 97.09% Max.Battery to ACEfficiency 96.69% MPPTEfficiency 99.99% Protection PVInsulat ion Resistance Detection lntegrated Residual Cu rrent Monitoring
Battery Rewerse Polarity Protectionlntegrated lntegrated An ti-islandingProtection lntegrated Acovercurrent Pro tection ln tegrated ACShort Circuit Protection lntegrated AcOvervoltageProtection lntegrated GeneralData per ating lemperature Range (C) -25°C+60°C Relative Humid ity 0~95% Max.OperatingAltitude(m) 4000M CoolingMethod NatureConvection Display LCD&APP communication with BMS"3 RS485;CAN communication with Meter RS485 communication with Portal Wi-F Weight(kg) 17 DimensionWXH×D(mm) 58D×433×175 Topology Non-is olated NoiseEmission (dB) 35 Self-consumption at Night(Wy4 10 lngressProtection Rating IP65 Mounting Method Wall Bracket Standard VDE-AR-N 4105:2018 EN 50549-1:2019 EN50549-1:2019 EC/EN 62109-1/-2 1EC/EN 61000-6-1/-2/-3/-4 VDE-AR-N 4105:2018 EN 300 328,(RED)
